Features

• High System Efficiency - Optimized system designs provide ENERGY STAR ratings in all tonnages. Targeted matches available in 1.5T thru 4T capacity meeting Federal Tax Credit efficiencies. 2 Ton thru 5 Ton feature 2-stage compressors
• Easier Installation - Independent panels provide quick access for unit setup. Installation time is reduced by easy power and control wiring access. The loose-ship filter-drier provides flexibility for field installation.
• Accessible Information - QR code on unit provides quick access to technical documents and warranty information.
• Durable Finish - The coated steel wire fan guard, coated external fasteners, and pre-treated G90-equivalent galvanized steel chassis components resist corrosion and rust creep. Modern Mist colored powdercoat paint further protects external panels.
• Quality Coils - The high efficiency microchannel aluminum coil is manufactured using an improved material system providing reliable performance and smaller unit size.
• Rugged Coil Protection - Coils are protected from mechanical damage by a proven stamped steel coil guard design.
• Protected Compressor - Compressors are protected internally by a high pressure relief valve and a temperature sensor, and externally by the system high and low pressure switches.
• Reliable Operation - ECM ball bearing fan motors provide superior performance in extreme temperatures.
• Environmentally Friendly - CFC-free LGWP R-454B refrigerant delivers environmentally friendly performance with zero ozone depletion.
• Top Discharge - Warm air is blown up, away from the structure and any landscaping and allows compact location on multi-unit applications.
• Low Operating Sound Levels - Specific sound and vibration development tests provide a design sound performance of 74 dBA or lower. Swept-wing fan blades are featured on units 2.5-Tons and higher. Compatible accessories for further sound reduction are also available.
• Better Service Access - Diagonal base valves with open access for low-loss fittings, straight tubing for line set connection flexibility, single panel access to the electrical controls, swing out control box for full corner access, and removable fan guard allow easy access for unit maintenance.
• Agency Listed - Safety certified by CSA to UL 1995 / CSA 22.2. Performance certified to ANSI/AHRI Standard 210/240 in accordance with the Unitary Small Equipment certification program.
